Power Take-Off ZF.13
ZF Power Take-Off (PTO)
Kozmaksan ZF Power Take OFFs designed for ZF series main transmissions. Kozmaksan ZF PTOs has Single&Double output models, Rear&Side Mounting type options and available for UNI&ISO mounting housing or suitable for flange connections.
ZF Power Take-Off (PTO)
- PTO for Heavy Duty
- Mounting Type: Rear PTO
- Control Type: Pneumatic
- Weight: 20 kg / 44 lb
- Sense of Rotation: Same as Engine Shaft
- 1 Year Warranty
- 10 Years Spare Parts Warranty
Options
- Engage/Disengage Sensor
- Second PTO Output
Applications
- Fire Fighting Truck
- Concrete Pumping Truck
- Water Truck
- Combined Cleaning Truck
| Max. Torque | 100 KGM / 980 Nm / 723 LBS-FT |
| Max. Power | 102 kW / 136 HP |
| Available Internal Ratios | 1/1.22 - 1/1.48 - 1/1.79 |
| Max. Speed | 3000 RPM |
