See technical data sheet for the chart.
Vertical Split Shaft PTOs Comparison Chart
| PTO PROPERTIES | UARA.400 | UARA.401 | UARA.801 | UARA.805 | UARA.2001 | UARA.2005 | UARA.3000 | UARA.4000 |
| Main Drive Torque (Intermittent) | 400 KGM | 400 KGM | 800 KGM | 800 KGM | 2000 KGM | 2000 KGM | 3000 KGM | 4000 KGM |
Distance between Top and Bottom Flange Centers | 223 mm (ratio 1/1.5 ) 214 mm (ratio 1/1.8 ) | 427 mm(ratio 1/1.5 ) 418 mm (ratio 1/1.8) | 270 mm | 541 mm | 270 mm | 541 mm | 422 mm | 422 mm |
| Axis Number | 3 | 5 | 3 | 5 | 3 | 5 | 3 | 3 |
| Top Output Power (Max.) | 82 KW | 82 KW | 135 KW | 135 KW | 135 KW | 185 KW | 350 KW | 360 KW |
| Top Output Ratios (Increaser) | 1/1,5 1/1,8 | 1/1,5 1/1,8 | 1/1 - 1/1,2 1/1,4 - 1/1,6 1/1,84 - 1/2,25 | 1/1 - 1/1,2 1/1,4 - 1/1,6 1/1,84 - 1/2,25 | 1/1 - 1/1,2 1/1,4 - 1/1,6 1/1,84 - 1/2,25 | 1/1 - 1/1,2 1/1,4 - 1/1,6 1/1,84 - 1/2,25 | 1/1 - 1/1,3 1/1,6 - 1/1,7 | 1/1 - 1/1,3 1/1,6 - 1/1,7 |
| Top Output Speed (Max.) | 3500 Rpm | 3500 Rpm | 3600 Rpm | 3600 Rpm | 3600 Rpm | 3600 Rpm | 2200 Rpm | 2200 Rpm |
| Weight (approx.) | 65 Kg | 85 Kg | 128 Kg | 175 Kg | 135 Kg | 180 Kg | 250 Kg | 265 Kg |
| Pump & Roll Feature | Available | Available | Available | Available | Available | Available | Available | Available |
| Cooling System (Optional) | Available | Available | Available | Available | Available | Available | Available | Available |
