Power Take-Off ISZ.08.MLD6A

Power Take-Off ISZ.08.MLD6A

Isuzu Power Take-Off (PTO)

Kozmaksan Isuzu Power Take OFFs designed for Isuzu trucks. Kozmaksan Isuzu PTOs has Single output model, Side Mounting type option and available for UNI&ISO mounting housing or suitable for flange connections. Depending on PTO output type, torque capacity reaches up to 45 KGM.

  • Kozmaksan Gearbox Code: ISZ.08.MLD6A
  • Suitable Transmission Codes: MLD-6A / MLD-6C,6E,7R,6B,6D,6F,6R,7Q,6G (8.761-6.720) / MLD-6S (6.307) / MRB-6P / LC6T70 (8.761-6.120)
  • Used Trucks
    4.8 FTR ISUZU / FTR 33P/ FTR33K / FNR / FVR5FF / FSR33L / FVR33P / LT132 / CHEVROLET FVR 32 ML / F110.210 EURO 4 / ISUZU FRR210 / FRR90HLH / LLH FTR240 / FTR34JLH QLH FVM230/200 / FVM33N2E / JAC /FTR33H / FVR33G
Share:

Isuzu Power Take-Off (PTO)

  • Mounting Type: Left Side PTO
  • Control Type: Pneumatic
  • Weight: 16 kg / 35,5 lb
  • Sense of Rotation: Opposite of Engine Shaft
  • 1 Year Warranty
  • 10 Years Spare Parts Back Up

Options

  • UNI & ISO & Flange Mountings
  • Engage/Disengage Sensor
  • Control Cabel and Lever with Mechanic PTOs

Applications

  • Garbage Truck
  • Crane Truck
  • Dump Truck
Max. Torque 45 KGM / 441 Nm / 325 LBS-FT
Max. Power 46 kW / 61 HP
Available Internal Ratios 1/1.28
Max. Speed 2000 RPM

ISZ.08.MLD6A Catalogue
